2x M.2; M.2_1 Source (From CPU) supports up to PCIe 4.0 x4
supports 2280/2260/2242 devices; M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4
supports 2280/2260/2242 devices; 4x SATA 6G;
I/O:
2x USB 2.0 (Rear); 4x USB 2.0 (Front); 2x USB 5Gbps Type A (Rear); 4x USB 5Gbps Type A (Front); 1x USB 5Gbps Type C (Front); 1x USB 10Gbps Type C (Rear); 1x Power Connector(ATX_PWR); 2x Power Connector(CPU_PWR); 1x CPU Fan; 1x Pump Fan; 5x System Fan; 2x Front Panel (JFP); 1x Chassis Intrusion (JCI); 1x Front Audio (JAUD); 1x Com Port (JCOM); 1x TBT connector (JTBT
supports RTD3); 2x Addressable V2 RGB LED connector (JARGB_V2); 2x RGB LED connector(JRGB); 1x TPM pin header(Support TPM 2.0); 4x USB 2.0 ports; 4x USB 5Gbps Type A ports; 1x USB 5Gbps Type C ports;
Connectors:
∙1x Front panel audio connector ∙2x System panel connectors; ∙1x Chassis Intrusion connector ∙1x TPM module connector; ∙1x Serial port connector ∙1x TBT connector (Supports RTD3);∙1x 4-pin CPU fan connector ; ∙1x 4-pin water-pump fan connector; ∙5x 4-pin system fan connectors;
Audio:
Realtek® ALC897 Codec; 7.1-Channel High Definition Audio; Supports S/PDIF output;
LAN:
Realtek® RTL8125BG 2.5G LAN
BIOS:
1x 256 Mb flash ∙UEFI AMI BIOS ∙ACPI 6.4
SMBIOS 3.5 ∙Multi-language
Form Factor:
ATX Form Factor ∙9.6 in. x 12 in. (244 mm x 304 mm)
