CPU:;- 2 x USB4 Type-C (Rear);- 2 x USB 3.2 Gen2 Type-A (Rear);Chipset:;- 1 x USB 3.2 Gen1 Type-C (Front);- 5 x USB 3.2 Gen1 Type-A (1 Rear
4 Front);- 8 x USB 2.0 (4 Rear
4 Front)
Производител:
ASRock
Wireless:
802.11be 2x2 Wi-Fi 7 Module;Supports IEEE 802.11a/b/g/n/ac/ax/be;Supports 2.4GHz/5GHz/6GHz frequency band;Supports 160MHz channel bandwidth with 6GHz frequency band;1 antenna to support 2 (Transmit) x 2 (Receive) diversity technology;Supports Bluetooth 5.4;Supports MU-MIMO
un-buffered memory up to 8000+(OC);Max. capacity of system memory: 256GB;Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules
80A Dr.MOS for VCore+SOC+MISC with Enlarged Heatsink Armor;- Flexible Integrated I/O Shield;Ultrafast Connectivity;- 2.5G LAN
802.11be Wi-Fi 7 Module;EZ Update;- BIOS Flashback Button;- ASRock Auto Driver Installer;EZ Troubleshooter;- ASRock Post Status Checker
CPU's supported:
Supports AMD Socket AM5 Ryzen™ 9000
8000 and 7000 Series Processors
Chipset:
AMD X870
Bluetooth:
5.4
Графика:
Integrated AMD RDNA™ graphics (Actual support may vary by CPU);- 1 x HDMI 2.1 TMDS/FRL 8G Compatible
supports HDR
HDCP 2.3 and max. resolution up to 4K 120Hz;- 2 x USB4
support HDCP 2.3 and max. resolution up to 8K 30Hz
Слотове:
CPU:;- 1 x PCIe 5.0 x16 Slot (PCIE1)
supports x16 mode;- 1 x PCIe 4.0 x16 Slot (PCIE3)
supports x4 mode;Chipset:;- 1 x PCIe 4.0 x16 Slot (PCIE2)
supports x1 mode*;- 1 x PCIe 4.0 x16 Slot (PCIE4)
supports x1 mode;- 1 x M.2 Socket (Key E)
supports type 2230 WiFi/BT PCIe WiFi module;- Supports AMD CrossFire™
Storage:
CPU:;- 1 x Blazing M.2 Socket (M2_1
Key M)
supports type 2280 PCIe Gen5x4 (128 Gb/s) mode;Chipset:;- 1 x M.2 Socket (M2_2
Key M)
supports type 2280 SATA3 6.0 Gb/s & PCIe Gen3x2 (16 Gb/s) modes;- 1 x Hyper M.2 Socket (M2_3
Key M)
supports type 2280 PCIe Gen4x4 (64 Gb/s) mode;- 4 x SATA3 6.0 Gb/s Connectors;Supports RAID 0
RAID 1 and RAID 10 for SATA storage devices;Supports RAID 0
RAID 1 and RAID 10 for M.2 NVMe storage devices
I/O:
2 x Antenna Ports;1 x HDMI Port;2 x USB4 Type-C Ports (40 Gb/s);2 x USB 3.2 Gen2 Type-A Ports (10 Gb/s);1 x USB 3.2 Gen1 Type-A Port;4 x USB 2.0 Ports;1 x RJ-45 LAN Port;1 x BIOS Flashback Button;HD Audio Jacks: Line in / Front Speaker / Microphone
Connectors:
1 x SPI TPM Header;1 x Power LED and Speaker Header;1 x RGB LED Header;3 x Addressable LED Headers;2 x CPU Fan Connectors (4-pin) (Smart Fan Speed Control);3 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control);1 x AIO Pump Fan Connector (4-pin) (Smart Fan Speed Control);1 x 24 pin ATX Power Connector;2 x 8 pin 12V Power Connectors (Hi-Density Power Connector);1 x Front Panel Audio Connector;2 x USB 2.0 Headers (Support 4 USB 2.0 ports);2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports);1 x Front Panel Type C USB 3.2 Gen1 Header
Audio:
7.1 CH HD Audio (Realtek ALC897 Audio Codec);Nahimic Audio
LAN:
2.5 Gigabit LAN 10/100/1000/2500 Mb/s;Dragon RTL8125BG;Supports Dragon 2.5G LAN Software;Smart Auto Adjust Bandwidth Control;Visual User Friendly UI;Visual Network Usage Statistics;Optimized Default Setting for Game
Browser
and Streaming Modes;User Customized Priority Control
